Meeting the maximum size requirements for testing building curtain wall air permeability, watertightness, resistance to wind pressure, and inter-story deformation performance: 6×10m (width × height).

01. Overview

• The building curtain wall testing equipment is capable of conducting four performance tests: air permeability, watertightness, resistance to wind pressure, and inter-story deformation performance of building curtain walls.
• It can test specimens such as framed curtain walls, unitized curtain walls, point-supported curtain walls, all-glass curtain walls, and point-supported curtain walls using tensioned cable/rod systems.

02. Video Introduction
Followed Follow Replay Share Like CloseWatch MoreMoreExitFull screenSwitch to vertical full screenExit full screenBeijing Zhongke Tianhao Technology Co., Ltd.FollowedShare video, duration 00:380/000:00/00:38 Switch to horizontal mode Continue playingProgress bar, 0% playing00:00/00:3800:38SpeedFull screen Playback speed 0.5x 0.75x 1.0x 1.5x 2.0x Ultra HD Smooth Your browser does not support the video tag Continue Watching Masterful Landing: Shanghai Building Curtain Wall Testing Equipment CompletedBeijing Zhongke Tianhao Technology Co., Ltd.FollowedShareLikeSaveAlready synced to FavoritesWritten comment Video Details

03. Applicable Standards
GB/T 21086-2007 Curtain wall for building
GB/T 15227-2019 Test method of air permeability, watertightness and wind load resistance performance for curtain walls
GB/T 18250-2015 Test method for inter-story deformation performance of building curtain wall
GB/T 29907-2013 Test method for watertightness of building curtain wall under dynamic wind pressure
JGJ/T 324-2014 Standard for test method of building curtain wall engineering
GB/T 38264-2019 Grade and test method for impact resistance performance of building curtain wall

04. Technical Parameters

• Equipment pressure box specifications and maximum testable specimen size: 6m × 10m (width × height). A platform is designed every 2.5m vertically on the curtain wall pressure box. Each partitioned platform or space within the pressure box is accessible via dedicated sealed doors. A staircase for personnel access is provided at the back of the pressure box, allowing entry into the pressure box through sealed doors on each level. Guardrails are installed at the front of the pressure box to protect installation personnel.
• Maximum static pressure: Absolute value >12kPa, accuracy 1Pa.
• Fluctuating pressure: At maximum pressure of 2500Pa, fluctuation cycle 3s–5s, target control value accuracy ±1.5%; for preliminary pressurization, cyclic pressurization, rating, and engineering tests, target control value accuracy ±2%.
• Water flow meter: 4 L/m²·min, measurement error not greater than 5% of indicated value.
• Deformation test: 1/100 (max ±120mm), cycle 3–5s, target control value accuracy ±1.5%, accuracy 0.1mm, range 0–250mm.
• Wind load resistance: Pressure > ±5000Pa, pressure accuracy ≤1%.
• Inter-story displacement: One set of inter-story deformation device, using servo motor and electro-hydraulic load loading device for inter-story deformation tests. Each direction of X, Y, Z axes can be loaded individually, and two or three directions can be loaded simultaneously. Thrust 1–5t, cycle 3s–10s. Displacement meter: 0–50mm, displacement accuracy ≤0.25% FS. Manual and automatic control of the test procedure is available.
• Water spray method: External spray system.
• Differential pressure gauge: Error ±1% of indicated value.
• Wireless displacement measurement: Range 0–150mm, accuracy 0.25% of full scale, 18 units provided. Wired displacement measurement: Range 0–50mm, displacement accuracy ≤0.01mm; 3 units provided. Displacement detection channels: 200.
• Measurement and control system: All test conditions and data acquisition/analysis are completed by computer, ultimately generating a complete report.
• The equipment supports various national standard pressurization modes. The software automatically controls the process, displays real-time pressure curves, includes sensor calibration, allows manual testing, provides free customized testing solutions, and supports remote monitoring and system interface expansion. Data uses an Access database; reports can be customized in Word format. The manufacturer is responsible on-site installation and commissioning and ensures installation quality.

05. Scope of Supply and Construction Work

• Model MQD60100 Building Curtain Wall Physical Performance Testing Equipment, covering all physical performance testing functions for curtain wall air permeability, watertightness, wind load resistance, and inter-story deformation.
• One 2-ton electric hoist included.
• One dedicated rainproof testing shelter included.
• Our scope of supply includes all associated foundation works and complete structural steel construction for this equipment: foundation excavation, cushion layer pouring, rebar binding, concrete foundation pouring, embedded anchor bolts, steel frame fabrication, installation, welding, anti-corrosion and anti-rust treatment, shelter steel structure erection, above-ground water tank civil and structural works, final finishing, etc. All construction and auxiliary works are supplied with labor and materials.
